Pro Audio Systems
HK12
AT A GLANCE
400W power capacity (8 hours pink noise)
Distortion free and natural reproduction
Good bass full range speaker without DSP
Optimized for smooth frequency response in and out axis
APPLICATIONS
HK12 loudspeaker system is suitable for near field main PA reinforcement with subwoofer for permanent installation.
Suitable in spaces like:
- KTV room
- Multi-functional room
- Trendy night club
SPECIFICATIONS
| Power handling (50~15000Hz pink noise 8 hours) | 400W / 800W Program |
| Nominal impedance | 8 Ohm |
| Frequency response (-6dB half space, no EQ) | 45~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity (wideband 200~16000Hz) | 99dB/W/m |
| Calculated Maximum SPL / 1m | 123dB continuous / 126dB Program |
| Nominal Directivity (-6dB) | 90º x 90º above 1300Hz |
| Recommended low cut filter |
40Hz 24dB/oct in full range mode 60-120Hz with subwoofer |
| Low Frequency driver | Custom made 12" |
| High Frequency driver | 1.75” Polymer diaphragm |
| Crossover | Passive mode only |
| Flying hardware | 11 M18 points |
| Connectors | 2x 4 (1+/1- Input) |
| Cabinet | CNC made with tongue and grove assembly |
| Finish | Touring grade textured black coating |
| Size (WxHxD) | 380*605*390mm |
| Weight |
20kg net, 22kg gross |
