Theater-K Speaker
CM6
AT A GLANCE
Real 150W RMS power capacity (8 hours pink noise)
HlFl sound for near field application
Coaxial driver with very good phase response
Premium custom made European driver
APPLICATIONS
CM6 loudspeaker system is suitable for nearfield
HlFl home concert reinforcement installation.
Suitable in spaces like,
-High fidelity music playback
-Multi-functional room
-Movie system playback
SPECIFICATIONS
| Power handling (50~15000Hz pink noise 8 hours) | 150W RMS/600W Peak |
| Nominal impedance | 8 Ohm |
| Frequency response | 65~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity (wideband 100~16000Hz) | 91dB/W/m |
| Calculated Maximum SPL /1m | 112dB continuous/118dB Peak |
| Nominal Directivity (-6dB) | 80°x80°(conical) above 1200Hz |
| Low Frequency driver |
Custom made 6.5" coaxial C-sichang driver
Ferrite magnet, 1.5” ln / Out Voice coil |
| High Frequency driver |
1”exit C-sichang
Neodymiun magnet, 1” coaxial HF |
| Crossover |
Passive mode only
3000Hz,12dB/oct on LF, 12dB/oct on HF |
| Connectors | Fasten connector |
| Cabinet |
CNC made with tongue and grove assembly
12+15mm high density wood |
| Finish | Walnut + black or white + gray, PVC coating |
| Size (WxDxH) | 480x150x205mm |
| Weight | 6.3kg net, 7.5kg gross |
