Theater-K Speaker
HB12
AT A GLANCE
450W High-power amplifier,300w driver
With lowpass corssover 50-120Hz adjustable
Balance XLR and 6.3mm jack signal input
12 inch premium custom made Long excursion driver
Designed with passive cone, compact box
Distortion free and natural reproduction
APPLICATIONS
HB12 loudspeaker system is suitable for near field
HlFl home concert reinforcement installation.
Suitable in spaces like:
- High fidelity music playback
-Multi-functional room
-High-grade solo concert
SPECIFICATIONS
| Power handling | 300W |
| Nominal impedance | 4 Ohm |
| Frequency response | 28~200Hz |
| Manufacturing Consistency tolerance | ±2dB from 50 to 200Hz |
| Average Sensitivity | 90dB/W/m |
| Calculated Maximum SPL | 113dB continuous/119dB Peak |
| Nominal Directivity (-6dB) | 360º |
| Low Frequency driver |
Custom made 12" C-sichang driver
Ferrite magnet, 2” Voice coil |
| Crossover | 50-120Hz adjustable |
| AC Power input | Universal power supply 110 or 220 VAC, 50 to 60 Hz |
| Connectors | RCA, balance XLR, and 6.3mmjack signal input |
| Amplifier Protection | Themmal limiting, output overcurrent, overtemperature muting |
| Cabinet |
CNC made with tongue and grove assembly
25+18mm high density wood |
| Finish | Black or white matte PVC |
| Size (WxHxD) | 428x930x428mm |
| Weight | 25kg |
