Karaoke Speaker
GOLD3
AT A GLANCE
Real 400W RMS power capacity
HIFI sound for near field application
Two-way with very good phase response
Premium custom made European driver
APPLICATIONS
Gold3 loudspeaker system is suitable for nearfield
HIFI home concert reinforcement installation.Suitable in spaces like:
- High fidelity musicplayback
- Multi-functional room
- High-grade solo concert
- High-grade home theater
SPECIFICATIONS
| Power handling (50~15000Hz pink noise 8 hours) | 400W RMS/1600W Peak |
| Nominal impedance | 4 Ohm |
| Frequency response | 36~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity (wideband 100~16000Hz) | 93dB/W/m |
| Calculated Maximum SPL /1m | 118dB continuous/124dB Peak |
| Nominal Directivity (-6dB) | 80°x80° above 1200Hz |
| Low Frequency driver |
Custom made 10" driver
Ferrite magnet, 2” In / Out Voice coil |
|
Mid Frequency driver
|
Custom made " 6.5 driver Aaudio
Ferrit 1.5 e magnet, ” In / Out Voice coil
|
| High Frequency driver |
1”exit
Neodymiun magnet, 1” coaxial HF |
| Crossover |
Passive mode only
500 and 28 2 00Hz, 12dB/oct on , 1 dB/oct on MF HF
|
| Connectors | Fasten connector |
| Cabinet |
CNC made with tongue and grove assembly
15mm high density wood |
| Finish |
white or black matte 7 layers finish
|
| Size (WxDxH) | 420x506x1306mm |
| Weight | 36.5kg net, 41kg gross |
