Karaoke Speaker
K10B
AT A GLANCE
300W High-power amplifier,200W driver
With lowpass corssover 50-120Hz adjustable
RCA signal input
10 inch premium custom made Long excursion driver
Designed with passive cone, compact box
Distortion free and natural reproduction
APPLICATIONS
K10B loudspeaker system is suitable fornear field
HIFl home concert reinforcement installation.
Suitable in spaces like.
-High fidelity music playback
-Multi-functional room
-High-grade solo concert
SPECIFICATIONS
| Power handling | 200W |
| Nominal impedance | 4 Ohm |
| Frequency response | 33~200Hz |
| Manufacturing Consistency tolerance | ±2dB from 50 to 200Hz |
| Average Sensitivity | 88dB/W/m |
| Calculated Mlaximum SPL | 111dB continuous /117dB Peak |
| Nominal Directivity (-6dB) | 360º |
| Low Frequency driver |
Custom made 10"C-sichang driver
Ferrite magnet, 2” Voice coil |
| Crossover | 50-120Hz adjustable |
| AC Power input | Universal power supply 220 -230 VAC, 50 to 60 Hz |
| Connectors | DualRCA, signal input |
| Amplifier Protection | Thermal limiting, output overcurrent, overtemperature muting |
| Cabinet |
CNC made with tongue and grove assembly
12+18mm high density wood |
| Finish | Black or white matte PVC |
| Size (WxHxD) | 328x390x390mm |
| Weight | 14.5kg |
