Karaoke Speaker
K68
AT A GLANCE
Real 250W RMS power capacity
HiFl sound for near field application
Two-way with very good phase response
Premium custom made European driver
APPLICATIONS
K68 loudspeaker system is suitable for nearfield
HIFl home concert reinforcement installation.
Suitable in spaces like:
-High fidelity music playback
-Multi-functional room
-High-grade solo concert
SPECIFICATIONS
| Power handling (60~15000Hz pink noise 8 hours) | 250W RMS/ 1000W Peak |
| Nominal impedance | 8 Ohm |
| Frequency response | 40~20000Hz |
| Manufacturing Consistency tolerance | ±2dB from 300 to 10000Hz |
| Average Sensitivity (wideband 100~16000Hz) | 92dB/W/m |
| Calculated Maximum SPL /1m | 116dB continuous/122dB Peak |
| Nominal Directivity (-6dB) | 80°x80° above 1200Hz |
| Low Frequency driver |
Custom made 8" C-sichang driver
Ferrite magnet, 2" In / Out Voice coil |
| High Frequency driver |
1” exit Csichang
Neodymiun magnet, 1” coaxial HF |
| Crossover |
Passive mode only
3000Hz,12dB/oct on LF, 12dB/oct on HF |
| Connectors | Fasten connector |
| Cabinet |
CNC made with tongue and grove assembly
15+25mm high density wood |
| Finish | white matte 7 layers finish |
| Size (WxDxH) | 330x370x540mm |
| Weight | 11kg net, 13kg gross |
